框架：Consists of welded construction front and rear main frames with structural tubing and fabricated side members. Front and rear frames are connected by an articulating joint allowing 15 degrees of up or down oscillation and 50 degrees right or left power steering action.

方面：Length = 35'6" Width = 9'5" Height = 11'6"

Weight:大约32,000磅（11793.6kg），标准28L26轮胎和旋转切割口。28,000（12700.8kg）W /粉碎机型切割口。

引擎：配有毛毛虫^®C7.1液冷柴油发动机额定为250马力（2200 rpm。发动机配备了排气消声器和大150.6kw）容量冷却系统。

Propel System:Hydrostatic 4-wheel drive with propel motor driving through a heavy-duty 2-speed powershift transmission.

Transmission and Axles:由重型Dana-SPICER 1550驱动轴连接到两个轴的2速移位转换。具有湿圆盘服务制动器的重型轴。后轴具有无旋转差分，前轴限制滑动。

Wheels, Tires and Brakes:轮胎：28L26 10-PLY记录仪类型轮胎标准。服务刹车是舷内湿盘式。驻车制动器是搬运防止式故障安全弹簧涂抹/液压释放的湿盘。

液压系统：Engine driven pump drive. Loadsense control hydraulic system. Hydrostatic propel system consists of closed-loop pump driving a hydraulic propel motor mounted on transmission. Charge loop filtration. Hydraulic reservoir mounted outside engine compartment with cleanout port and shutoff valve. Cutterhead hydraulic circuits consist of one closed loop hydrostatic system with variable displacement pump and fixed displacement motors.

电子系统：24 volt dc negative ground with engine driven 115 amp alternator and two 12-volt batteries w/950 cold cranking amps each.

出租车：Angled front roof profile equipped with 1 1/4” (31.8mm) thick tinted Lexan roof viewing window. Equipped with joystick control for cutterhead lift and tilt functions. Fully enclosed cab with heater and air conditioner. Fully adjustable seat with suspension, seat belts and lumbar support. Front windshield wiper, dome light, Lexan windows, front window guard, electric horn and full engine instrumentation are standard.

Capacities: Fuel tank:100加仑（379L）。液压罐：85 gallons (322l).

地面清关：With 28L26 tires: 23” (584.2mm).

Optional Equipment:Optional tire sizes: 28L26 or 67x34.00-25. Other options available upon request.
