框架：焊接结构，下框架是结构钢和1“（25.4毫米）厚钢板，用于回转环支撑。上甲板是结构钢和成型甲板。五（5）年保修所涵盖的框架。超大46 7/8英寸直径的回转环，额定为80,000 ft-lb。用于回转环和轴轴承的远程润滑脂配件。8通道6,000 PSI液压旋转可从上甲板接近。

引擎：Caterpillar C4.4, 131 HP @ 2200 rpm Tier IV Final

Transmission and Axles:3英寸(76毫米)直径实心轴chain drive from separate hydraulic motors driving both axles. Travel speed: 20 mph (32 km/hr). Two (2) propel drive motors for quicker response in work mode. #100 drive chain with hardened tooth sprockets.

液压系统：Hydrostatic propel system pressure compensated piston-type pump direct coupled to engine. Deck rotation by hydraulic motor through gearbox. Hydraulic oil is filtered through a 100 mesh (145 micron) suction screen and 10-micron return line filter. Manifold-type stack valves for improved serviceability. Remote oil cooler accessible from ground level with dual electric cooling fans. Electric emergency pump.

电子系统：24VDC负面，100AMP交流发电机，颜色编码和编号接线。

Air System:空压机，发动机油润滑，风冷;压力 - 100-120 PSI（689-927 KPA），15加仑的空气罐。

出租车：Large enclosed cab with 99.5 cubic foot capacity. Ergonomically designed seat. Large front windshield with an unobstructed view of boom operation through full range of motion. Hydraulic pilot-pressure bottom-ported joystick controls on operator seat with heat shields. Self-contained hydraulically driven air conditioner/heater/pressurizer unit mounted on rear wall of cab (roof mount optional). Remote-controlled boom travel lock. Rubber suspension ladder steps. No service items located on cab roof on standard machine.

Wheels and Brakes:16“（406毫米）铸钢轮。外部，个体复合制动鞋直接施加在车轮胎面的垂直中心线上。服务制动器是空气，春季释放。紧急/停车制动器是春天应用的，空气释放。可选的液压制动器可用。

能力：燃油：75加仑。（284升），液压：70加仑。（265升）。

Weight:23,000磅

繁荣：超宽32英寸（813毫米）扩散底根臂安装。GV-12抓斗旋转器。配备4,000磅的容量绞车。

Optional Equipment:篮子擒抱;单领带擒抱;两个领带擒抱;木材擒抱;混凝土领带擒抱;木材起重机包;蓬勃发展的羊盘割草机。
